La bomba centrífuga K-HA (monoturbina) está diseñada para presurización en casas y departamentos (aplicaciones domésticas), para proveer de agua presurizada tanto caliente como fría. La bomba K-HA está intencionada
single impeller centrifugal pump is designed for boosting water pressures in houses and apartments (domestic properties), in order to provide additional pressure to hot and cold water taps and similar outlet points. The K-HA centrifugal pump is mainly intended for use in open vented systems(tanks), but may also be installed directly on the incoming water mains supply feeding a boiler, subject to the approval of the local Water Authority. The pump incorporates a flow switch that starts and stops the pump in line with the flow, when a tap is opened or closed. The pump is supplied with a 0,3 meter power cable.
Operating range: up to 4,2 m3/h with head up to 22 m.
Maximum operating pressure: 4 bar (liquid temperature 35° C), 2 bar (liquid temperature 65° C).
Liquid temperature range: from 0 °C to +100 °C.
Humidity: ≤ 95%.
